    Solid CrAl15-5 FeCrAl Heating Resistance Wire For Furnace

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : Cr15Al5
    Certification : ISO9001
    Price :
    Payment Terms : L/C, T/T, , Western Union
    Supply Ability : 120+ton+per month
    Delivery Time : 8-15 days
    • Product Details
    • Company Profile

    Solid CrAl15-5 FeCrAl Heating Resistance Wire For Furnace

    CrAl15-5 FeCrAl Heating Resistance Alloy Wire for Furnace Heating

    Cr15Al5 Eurofechral

    materialgradeUNS nameDINDensityASTM
    fecral1.4725K 92500174707.4B 603-1

    The main applications:kilns,resistor elements,high-temperature furnaces,industrial tubular heating elements and heaters.


    Percentage Composition:

    AlCrFeMnCSiNiCuTiOtherRare earth elements
    4.6-5.814.5-15.5BasisMax0.7till 0.05till 0.6till 0.6...till 0.6Zr≤0.3...

    Resistance Wire:
    1)Iron Chrome Aluminum Wire
    CrAl 14-4, CrAl 15-5, CrAl 20-5, CrAl 25-5, etc.

    2)Nichrome Wire
    NiCr 80/20, NiCr 70/30, NiCr 60/15, NiCr 35/20

    3)Nickel Copper Alloy Wire
    Alloy 30, Alloy 60, Alloy 90, Constantan Wire

    For more details, pls visit our website or email us.

    SPECIFICATIONS:

    1Cr13Al40.03-12.01.25±0.08588-735>16>6950>10000
    0Cr15Al51.25±0.08588-735>16>61000>10000
    0Cr25Al51.42±0.07634-784>12>51300>8000
    0Cr23Al51.35±0.06634-784>12>51250>8000
    0Cr21Al61.42±0.07634-784>12>51300>8000
    1Cr20Al31.23±0.06634-784>12>51100>8000
    0Cr21Al6Nb1.45±0.07634-784>12>51350>8000
    0Cr27Al7Mo20.03-12.01.53±0.07686-784>12>51400>8000

    Relevance:


    Fecrak us an ideal alloy with an excessive specific real resistance(1.20-1.30 ohm-mm2/m)which combine a heat resistance up to 1450C and is claimed to be indispensable at temperature extremes.These properties allow using this alloy extensively while manufacturing heating units. It has a perfect corrosive resistance on air,in argon, in a vacuum, oxidizing, sulfur-containing and carboniferous environments.It shows not very high relative density(7.2g/cm3),but it has a great yield limit.


    Mechanical Characteristics T°20°C


    Number of bowingsPercentage Extension
    >5 times>16%

    Phyiscal Characteristics T°20°C

    HardnessDensityBreaking loadMaximum Working temperature 850CElectrical resistivityMagnetismMelting points (°C)
    200-260 HB7.1g/cm3637-784m/pa1.30 ohn-mm2/mMagnetic1400 °C
