    Factory Prices and High Quality Beryllium Copper Alloy Strip C17200 CuBe strip

    Ask Lasest Price
    Brand Name : TANKII
    Model Number : C17200
    Price : 25USD/KG
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 10TON/MONTH
    Delivery Time : 10DAYS
    • Product Details
    • Company Profile

    Factory Prices and High Quality Beryllium Copper Alloy Strip C17200 CuBe strip

    Basic Info.

    Model NO.
    C17200
    Shape
    Coil
    Density
    8.4(g/cm3)
    Sample
    Small Order Accepted
    surface
    Bright
    colour
    Bronze
    Elongation
    30%
    Other Name
    CB101
    Product Type
    copper Alloy
    Type
    Copper Strips
    Application
    Water Heater, Air Condition or Refrigerator, Oil Cooler Pipe, Water Tube
    Alloy
    Alloy
    Standard
    ASTM
    Transport Package
    in Roll, in Woodencase Outside
    Specification
    thick: 0.01-5mm, width: 1-600mm
    Trademark
    TANKII
    Origin
    Shanghai, China
    HS Code
    7409400000
    Production Capacity
    5000 Ton/Year

    Product Description

    BeCu bar / C17200 Beryllium copper Strip / Sheet/rob/Foil

    Unusual wear resistance
    High property levels
    High yield strength
    High hardness values

    Beryllium Copper Chemical Composition
    ASTMCuNiCoBe
    C17200Balance111.80-2.10
    C17000Balance111.60-1.85
    C17300Balance111.85-2.10
    ASTMCuNiCoBe
    C17500Balance-2.4-2.70.4-0.7
    C17510Balance1.4-2.20.30.2-0.6

    beryllium copper C17200
    Cube2--C17200 (CDA 172) Beryllium Copper is the most commonly utilized Copper Beryllium alloy and is notable for its highest strength and hardness compared to commercial copper alloys. C17200 alloy contains appr. 2% of beryllium and achieves its ultimate tensile strength can exceed 200 ksi, while the hardness approaches Rockwell C45. Meanwhile, the electrical conductivity is a minimum of 22% IACS in the fully aged condition.C17200 also exhibits exceptional resistance to stress relaxation at elevated temperatures.

    Chemical Composition
    ElementComponent
    Be1.85-2.10%
    Co+Ni0.20% Min
    Co+Ni+Fe0.60% Max.
    CuBalance

    Typical Physical Properties
    Density (g/cm3)8.36
    Density before age hardening (g/cm38.25
    Elastic Modulus (kg/mm2 (103))13.40
    Thermal Expansion Coefficient (20 °C to 200 °C m/m/°C)17 x 10-6
    Thermal Conductivity (cal/(cm-s-°C))0.25
    Melting Range (°C)870-980

    Mechanical property:(before heat treatment)
    statusTensile strength
    (Kg/mm3)
    Hardness
    (HV)
    Conductivity
    ( IACS%)
    Elongation
    (%)
    H70-85210-240222-8
    1/2H60-71160-210225-25
    042-5590-1602235-70

    Mechanical property:(after heat treatment)
    statusTensile strength
    (Kg/mm3)
    Hardness
    (HV)
    Conductivity
    (IACS%)
    Elongation
    (%)
    H130-151380-420221-5
    1/2H126-147370-410222-7
    0112-135350-339223-11

    Features

    1. High thermal conductivity
    2. High corrosion resistance, especially suitable for polyoxyethylene (PVC) products mold.
    3. High hardness, wear resistance and toughness, as inserts used with mould steel and aluminium can make the mold play a highly efficient, prolong the service life.
    4. Polishing performance is good, can achieve high mirror surface precision and complicated shape design.
    5. Good tackiness resistance, easy to welding with other metal, easy to machining, there is no need additional heat treatment.

    Applications

    Beryllium Copper is widely used in mold core, injection mold insert, mold cavity, corrosion resistant die, die casting
    machine head, watering the crossing thimble, the punch mould parts, hot runner system such as accessories,
    stretching die, casting mould, die-casting mould, and corrosion resistant wear resistant parts such as bearings,worm gear etc.
