    FeCrAl Alloy Wire 0.6mm 1.2mm High Temperature Resistance Heating

    Ask Lasest Price
    Brand Name : Tankii
    Model Number : 1cr13al4 0cr25al5
    Certification : IOS
    Price : 4.5USD/Kg
    Payment Terms : T/T,D/P,D/A,L/C,Western Union,MoneyGram
    Supply Ability : 1000kgs One Week
    Delivery Time : 10-15days
    • Product Details
    • Company Profile

    FeCrAl Alloy Wire 0.6mm 1.2mm High Temperature Resistance Heating

    Hot Selling Fecral 0.6mm 1.2mm High Temperature 16AWG 1cr13al4 0cr25al5 Fecral Wire

    Resistance Alloy Wires is used for electrical heating element.

    Widely used in metallurgy, industrial stoves, household appliances, machinery and electronics manufacturing industries do heat resistance material.

    1.FeCrAl Electrictrical Resistance Heating alloys with high electrical resistivity, temperature coefficient of resistance is small, high operating temperature. good corrosion resistance under high temperature, and particularly suitable for use in a gas containing sulfur and sulfides, low price, it is widely used in industrial electric furnace, household appliances, far infrared device ideal heating material.

    FeCrAl type:1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5, 0Cr21AI6 Nb, 0Cr27AI7Mo2 etc.Series electric flat belt, electric fire wire

    Grades
    1Cr13AL4
    1Cr21AL4
    0Cr21AL6
    0Cr23AL5
    0Cr25AL5
    0Cr21AL6Nb
    0Cr27AL7Mo2
    Main chemical composition%
    Cr
    12.0-15.0
    17.0-21.0
    19.0-22.0
    20.0-23.5
    23.0-26.0
    21.0-23.0
    26.5-27.8
    AI
    4.0-6.0
    2.0-4.0
    5.0-7.0
    4.2-5.3
    4.5-6.5
    5.0-7.0
    6.0-7.0
    Fe
    balance
    balance
    balance
    balance
    balance
    balance
    balance
    Re
    appropriate
    appropriate
    appropriate
    appropriate
    appropriate
    appropriate
    appropriate
    Components maximum use temperature
    950
    1100
    1250
    1250
    1250
    1350
    1400
    Melting point
    1450
    1500
    1500
    1500
    1500
    1510
    1520
    Density g/cm3
    7.4
    7.35
    7.16
    7.25
    7.1
    7.1
    7.1
    Resistivity μΩ·m,20
    1.25±0.08
    1.23±0.06
    1.42±0.07
    1.35±0.06
    1.42±0.07
    1.45±0.07
    1.53±0.07
    Tensile strength Mpa
    588-735
    637-784
    637-784
    637-784
    637-784
    637-784
    686-784


    2.Nickel chromium alloy with iron resistance electrothermal high resistivity. At high temperature and high intensity, and a good performance and processing may welding nature widely used metallurgical, electrical, mechanical components and electrical manufacturing industries for doing heat resistance material.

    Ni-Cr Type:Cr20Ni80,Cr15Ni60, Cr20Ni35, Cr20Ni30, Cr25Ni20 etc.Series electric flat belt, electric fire wire.

    Grade

    Ni80Cr20

    Ni70Cr30

    Ni60Cr15

    Ni35Cr20

    Ni30Cr20

    Chemical composition %

    Ni

    Balance

    Balance

    55.0~61.0

    34.0~37.0

    30.0~34.0

    Cr

    20.0~23.0

    28.0~31.0

    15.0~18.0

    18.0~21.0

    18.0~21.0

    Fe

    ≤1.0

    ≤1.0

    Balance

    Balance

    Balance

    Highest service temperature °C

    1200

    1250

    1150

    1100

    1100

    Melting point °C

    1400

    1380

    1390

    1390

    1390

    Density g/cm3

    8.40

    8.10

    8.20

    7.90

    7.90

    Resistivity μΩ.m,20°C

    1.09

    1.18

    1.12

    1.0

    1.04

    Specific heat J/g.°C

    0.440

    0.461

    0.494

    0.500

    0.500

    Thermal conductivityKJ/m.h.°C

    60.3

    45.2

    45.2

    43.8

    43.8
