    Tankii 0Cr23Al5 Resistance Alloy Wire 0.5mm With DIN125 Spool

    Ask Lasest Price
    Brand Name : Tankii
    Model Number : 0Cr23Al5
    Price : USD+4USD/KG
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 10TON/MONTH
    Delivery Time : 10days
    • Product Details
    • Company Profile

    Tankii 0Cr23Al5 Resistance Alloy Wire 0.5mm With DIN125 Spool

    Product Description

    0Cr23Al5 resistance alloy wire 0.5mm with DIN125 spool stock price used for resistor

    Tankii supplies in the form of wire, foil, rod, bar, strip, sheet of 0Cr23Al5


    0Cr23Al5 is a ferritic iron-chromium-aluminium alloy (FeCrAl alloy) for use at temperatures up to 1300°C (2370°F). The alloy is characterized by high resistivity and good oxidation resistance.


    Main specifications and uses:
    Conventional Product specifications: 0.07 ~ 10 mm

    Uses: Mainly used in
    home appliances and industrial furnaces
    User Manual
    1. Rated Voltage: 220V/380V
    2. The installation process to avoid knocking, to avoid the damp, hand-held stove wire, they should wear gloves. Wire should be installed after the furnace has remained flat, and prevent surface scratches, dirt, corrosion, or improper installation, by affecting the life of
    3. In the rated voltage to use. In strong reducing atmosphere, acid atmosphere, an atmosphere of high humidity will affect the use of life;
    4. Temperature before use should be in dry non-corrosive atmosphere, about 1000ºC spend a few hours, so that furnace wire protective film formed on the surface after normal use, so that can guarantee the normal life of furnace wire;
    5. Furnace installation should ensure that the insulated wire good power to avoid touching furnace after the wire, guard against electric shock or burns.

    If there is any question, pls be free to tell us.
    Properties Grade0Cr23Al5
    CrAlReFe
    22.5~24.54.2~5SuitableBalance
    Max Continuous Service Temperature(º C)1250
    Resisivity 20º C (Ω mm2/m)1.35
    Density(g/cm 3 )7.25
    Approximate Melting Point( º C)1500
    Elongation (%)12
    Repeatedly Bend Frequency(F/R) 20º C>5
    Hardness HB200~260
    Micrographic StructureFerrite

    0Cr23Al5 resistance alloy wire 0.5mm with DIN125 spool
