High Quality Ni200/Ni201/Ni6 Pure Nickel Band For 18650 Batteries

Product Categories

Copper Nickel Alloy Wire [359]
Electric Resistance Wire [349]
Thermocouple Bare Wire [211]
FeCrAl Alloy [316]
Thermocouple Cable [249]
Nicr Alloy [469]
Thermal Spray Wire [220]
Furnace Heating Element [66]
Precision Alloy [341]
Copper Alloy [76]
Nickel Alloy [159]
Enamelled Wire [78]
High Temp Alloy [68]
Thermocouple Connector [30]

Shanghai Tankii Alloy Material Co.,Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Ni6 Pure Nickel Band For 18650 Batteries

Ask Lasest Price
Brand Name :	TANKII
Model Number :	Ni200
Certification :	ISO9001
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	1000 tons/year
Delivery Time :	5~14 dyas after getting the payment

Add to Cart

Product Details
Company Profile

High Quality Ni200/Ni201/Ni6 Pure Nickel Band For 18650 Batteries

High Quality Ni200/Ni201/Ni6 Pure Nickel Band for 18650 Batteries

It has good mechanical strength,corrosion-resistant and heat-resistance strength.

It is widely used in electric apparatus,chemical machinery,good processing equipment,rechargeable batteriesomputers, cellular Phone, power tools, camcorders and so on.

Chemical Composition

Grade	Element Composition/%
Grade	Ni+Co	Mn	Cu	Fe	C	Si	Cr	S
Ni201	≥99.0	≤0.35	≤0.25	≤0.30	≤0.02	≤0.3	≤0.2	≤0.01
Ni200	≥99.0	/≤0.35	≤0.25	≤0.30	≤0.15	≤0.3	≤0.2	≤0.01

Propertis

Grade	Density	Melting point	Coefficient of expansion	Modulus of rigidity	Modulus of elasticity	Electrical resistivity
Ni200	8.9g/cm3	1446°C	13.3 µm/m °C (20-100°C)	81kN/mm2	204kN/mm2	9.6μW• cm
Ni201	8.9g/cm3	1446°C	13.1µm/m °C(20-100°C)	82kN/mm2	207kN/mm2	8.5μW• cm

Diameter(mm)	Tolerance(mm)	Diameter(mm)	Tolerance(mm)
0.03-0.05	±0.005	>0.50-1.00	±0.02
>0.05-0.10	±0.006	>1.00-3.00	±0.03
>0.10-0.20	±0.008	>3.00-6.00	±0.04
>0.20-0.30	±0.010	>6.00-8.00	±0.05
>0.30-0.50	±0.015	>8.00-12.0	±0.4

Specification of Cold-drawing Strip Type

Thickness(mm)	Tolerance(mm)	Width(mm)	Tolerance(mm)
0.05-0.10	±0.010	5.00-10.0	±0.2
>0.10-0.20	±0.015	>10.0-20.0	±0.2
>0.20-0.50	±0.020	>20.0-30.0	±0.2
>0.50-1.00	±0.030	>30.0-50.0	±0.3
>1.00-1.80	±0.040	>50.0-90.0	±0.3
>1.80-2.50	±0.050	>90.0-120.0	±0.5
>2.50-3.50	±0.060	>120.0-250.0	±0.6

Type	Dimension(mm)	Cell spacing(mm)	Width	Dimension of the square hole(mm)	Nickel Plated Steel Strip	Pure Nickel	Type of battery pack
Type	Dimension(mm)	Cell spacing(mm)	Width	Dimension of the square hole(mm)	Length for per Kg(m)		With holder	Without holder
1P 18650 Nickel strip	0.15 x 7 x 18.4	18.4	7	-	128.3	112.6		√
	0.15 x 7 x 19	19		-	127.9	112.1	√
	0.15 x 7 x 19.5	19.5		-			√
	0.15 x 7 x 20.25	20.25		-	127.6	111.9	√
2P 18650 Nickel strip	0.15 x 26 x 19(13.5 x 13.5)	19	26	12 x 12	47.2	41.4	√
	0.15 x 27 x 19.5(12 x 14.5)	19.5	27	12 x 14.5	48.9	42.9	√
	0.15 x 27 x 19.75(12.5 x 12.5)	19.75		12.5 x 12.5	47	41.2	√
	0.15 x 27 x 20.25(13.5 x 13.5)	20.25		13.5 x 13.5	48.9	42.9	√
2P 18650 Nickel strip	0.15 x 25.5 x 18.4 (11 x 12.5)	18.4	25.5	11 x 12.5	48.9	42.9		√
Dislocation 2P 18650 Nickel strip	0.15 x 25.5 x 18.4(8 x 9.5)	18.4		8 x 9.5	41.1	36.1		√
Dislocation 2P 18650 Nickel strip	0.15 x 25.5 x 19.5(8 x 9.5)	19.5		8 x 9.5	38.6	33.8	√
3P 18650 Nickel strip	0.15 x 44.5 x 18.4(11 x 12.5)	18.4	44.5	11 x 12.5	27.4	24		√
	0.15 x 4245 x 19(12 x 12)	19	45	12 x 12	29.1	25.5	√
	0.15 x 47.5 x 20.25(12.65 x 12.65)	20.15	47.5	12.65 x 12.65	27.4	24	√
	0.15 x 47.5 x 20.25(13.5 x 13.5)	20.25	47.5	13.5 x 13.5	29.4	25.7	√
4P 18650 Nickel strip	0.15 x 63 x 18.5(11 x 12.5)	18.5	63	11 x 12.5	21.6	18.9		√
	0.15 x 64 x 19 (12 x 12)	19	64	12 x 12	21	18.4	√
	0.15 x 67.95 x 20.15(12.65 x 12.65)	20.15	67.95	12.65 x 12.65	19.6	17.2	√
	0.15 x 67.7 x 20.25(13.5 x 13.5)	20.25	67	13.5 x 13.5	21.3	18.7	√
5P 18650 Nickel strip	0.15 x 83 x 19(12 x 12)	19	83	12 x 12	16.4	14.4	√
	0.15 x 88.1 x 20.15(12.65 x 12.65)	20.15	88.1	12.65 x 12.65	19.7	17.3	√
	0.15 x 87.9 x 20.25(13.5 x 13.5)	20.25	87.9	13.5 x 13.5	16.7	14.6	√
6P 18650 Nickel strip	0.15 x 102 x 19 (12 x 12)	19	102	12 x 12	13.5	11.9	√
	0.15 x 108.25 x 20.15	20.15	108.25	12.65 x 12.65	12.6	11	√
	0.15 x 108.1 20.25(13.5 x 13.5)	20.25	108.1	13.5 x 13.5	13.7	12	√
7P 18650 Nickel strip	0.15 x 121 x 19 (12 x 12)	19	121	12 x 12	11.5	10	√
	0.15 x 128.4 x 20.15(12.65 x 12.65)	20.15	128.4	12.65 x 12.65	10.7	9.4	√
	0.15 x 128.3 x 20.25(13.5 x 13.5)	20.25	128.3	13.5 x 13.5	11.6	10.2	√
8P 18650 Nickel strip	0.15 x 140 x 19 (12 x 12)	19	140	12 x 12	10	8.7	√

Typical application areas for battery

High Quality Ni200/Ni201/Ni6 Pure Nickel Band For 18650 Batteries

Should have any question, please contact us freely.
